These compound feed post bed machines derive their feeding power from a top driven roller presser foot and a bottom driven roller wheel feed dog. They are designed with a link lever thread take up and use a timing belt to transfer power from the main shaft to the hook shaft. Needle bearings and ball bearings are used in critical positions thereby ensuring smooth and quiet operation. They are used in sewing such small radius items as leather shoes, handbags, gloves, caps and similar articles.
Model GC20618-CX
One needle post bed with top driven roller feed and bottom wheel feed for thick thread
Model GC24618-1CX
Two needle (3/32 gauge) post bed with top driven roller feed and bottom wheel feed for thick thread
(This machine comes with a table and motor assembled)
| Machine Type | Post Bed Compound Feed Lockstitch (Roller Feed) |
|---|---|
| Needle | Single / Double Needle (depending on subclass) |
| Feed Mechanism | Compound Feed (Top & Bottom Driven Roller + Needle Feed) |
| Max. Sewing Speed | 3,000 Stitches per Minute |
| Stitch Length | 1.3 ~ 7 mm |
| Needle Bar Stroke | 38 mm |
| Presser Foot Lift | 7 mm (by hand), 14 mm (by knee) |
| Post Height | 178 mm |
| Needle System | DP x 5 (#11 ~ #14) |
| Hook Type | Vertical Axis Hook |
| Lubrication | Manual / Semi-Automatic |
| Motor | Servo Motor 220V 550W (depending on subclass) |
| Machine Setup | Complete with Table & Motor (Assembled) |
Create unlimited custom tabs and add any product detail, module, widget, design or HTML. Also possible to create custom tab layout using layout builder
Highlead GC24618 Series Industrial Sewing Machines with Assembled Table and Servo Motor
- Product Code: GC24618
These compound feed post bed machines derive their feeding power from a top driven roller presser foot and a bottom driven roller wheel feed dog. They are designed with a link lever thread take up and use a timing belt to transfer power from the main shaft to the hook shaft. Needle bearings and ball bearings are used in critical positions thereby ensuring smooth and quiet operation. They are used in sewing such small radius items as leather shoes, handbags, gloves, caps and similar articles.
Model GC20618-CX
One needle post bed with top driven roller feed and bottom wheel feed for thick thread
Model GC24618-1CX
Two needle (3/32 gauge) post bed with top driven roller feed and bottom wheel feed for thick thread
(This machine comes with a table and motor assembled)
| Machine Type | Post Bed Compound Feed Lockstitch (Roller Feed) |
|---|---|
| Needle | Single / Double Needle (depending on subclass) |
| Feed Mechanism | Compound Feed (Top & Bottom Driven Roller + Needle Feed) |
| Max. Sewing Speed | 3,000 Stitches per Minute |
| Stitch Length | 1.3 ~ 7 mm |
| Needle Bar Stroke | 38 mm |
| Presser Foot Lift | 7 mm (by hand), 14 mm (by knee) |
| Post Height | 178 mm |
| Needle System | DP x 5 (#11 ~ #14) |
| Hook Type | Vertical Axis Hook |
| Lubrication | Manual / Semi-Automatic |
| Motor | Servo Motor 220V 550W (depending on subclass) |
| Machine Setup | Complete with Table & Motor (Assembled) |
- Brand: Highlead
- Viewed: 29
- Availability: In Stock
$1,660.00
