Centra-Lube® Semi-Automatic Lubrication System, Large Vertical Axis Hooks and Bobbins, Reverse Feed, Safety Clutch

Applications

• Designed for stitching light to medium weight fabrics.
• Designed for stitching reinforced and parallel stitches.
• Suitable for operations such as attaching zippers, lap seam felling, staying shoe linings, and general double needle seaming, binding, taping, and piping.

Features

• Large vertical axis hooks and bobbins ensure longer operation between bobbin changes.
• Centra-Lube® semi-automatic lubrication system.
• Automatic hook lubrication.
• Oil-fed take-up.
• Reverse stitching.
• Large range of gauge sets available.
• Safety clutch prevents the hooks from being damaged.
• Synchronized puller available (add suffix -P).

Specifications

• Number of Needles: 2 (Double)
• Feeding Mechanism: Needle Feed
• Workspace: Standard Workspace
• Standard or Full Function: Standard Functions
• Speed, Max (S.P.M.): 2800
• Clearance Under Presser Foot: 2 1/64" (8.5mm)
• Stitch Length: 4 s.p.i. (6.5mm)
• Work Space: 10" (254mm)
• Needle: 135 x 17
• Bobbin: Pre-Wound S or U
• Bed Size: 7" x 20-3/8" (177mm x 518mm)
• Stitch Type: 301
• Weight: 96 lbs
• Needle Bar Stroke: 1 5/16" (33mm)
• Available Needle Spacings: 1/16" (1.6mm) - 1 1/2" (38.1mm)
• Standard Needle Spacing: 1/4" (6.4mm)
• Hook: 15502
